Bolt Preload Modeling Methods

This presentation was made at NAFEMS UK Conference 2018, Taking Engineering Analysis and Simulation to the Next Level".

The NAFEMS UK Conference 2018 brought together all those involved in analysis and simulation from every corner of industry and academia, giving them an opportunity to advance their knowledge, give their organisations a competitive advantage, and a chance to be part of improving the technology itself.

Resource Abstract

Preloaded bolts are used in finite element analysis to model the behavior of two or more parts being held together while undergoing mechanical, thermal or other loading conditions. Such a modeling scenario typically requires the bolts to be preloaded to a specified value and a set of contact regions to be established between the parts held together by the bolt. This is done by either specifying a load or a bolt shortening. The resulting preload can be identified by studying the internal forces within the bolt shaft or by the contact forces between the various parts that are held together.



The bolt preloading approach that currently exists in various commercial solvers involves defining beams or solid elements that form the bolt shaft and specifying a location where the solver cuts the model perpendicular to the bolt axial direction. The requested load or a shortening is applied axially on either side of the cut in opposite directions while reducing the axial stiffness along the bolt axial direction. This causes the part to shorten whereby each cut plane penetrates the other resulting in a tension that equals the requested preload. This method of preloading bolts is well-known to finite element users and has a high degree of accuracy and reliability.



An alternate, novel approach to preload bolts is presented here wherein the preload or shortening is applied as an initial strain along the bolt. Here, the user selects a set of elements that form the bolt shaft along with a bolt axial direction. Numerically, the user defined preload is applied as an initial strain on the selected elements and does not require the shaft to be cut. The resulting initial strain may need to be iterated upon until the internal forces in the bolt elements match the user requested preload. Comparison of the cut approach and the initial strain approach results will be presented. Realistic model showing application of the initial strain method will also be presented.

Document Details

ReferenceC_Jul_18_UK_29
AuthorRavindren. P
LanguageEnglish
TypePresentation
Date 17th July 2018
OrganisationSiemens PLM Software
RegionUK
