Finite Element Benchmarks for 2D Beams & Axisymmetric Shells Involving Nonlinear Geometric Behaviour

This report is one of a series commissioned by NAFEMS.

The purpose of these reports is to provide a set of benchmark tests against which the results of different finite element programs can be compared. The report is concerned with solutions to problems involving thin two-dimensional beams and axisymmetric shells undergoing large displacements and rotations

Problems involving deep beams, large strains or non-conservative loading are specifically excluded.

Furthermore the beams and axisymmetric shells are assumed to have elastic material properties and a prismatic cross section.The emphasis on the results in this report lies in the area of displaced shapes and thus most of the target results quoted relate to displacements rather than internal stresses. However, stress resultant plots obtained from the Finite Element solutions have been included for all the beam tests along with values for stress resultants obtained by simple statics for those tests which are statically determinate.


Document Details

ReferenceP10
AuthorsLyons. P Holsgrove. S
LanguageEnglish
AudienceAnalyst
TypePublication
Date 1st January 1989
RegionGlobal

Download

Purchase Book

Order RefP10 Book
Member Price £17.50 | $22.07 | €20.41
Non-member Price £52.50 | $66.21 | €61.22

Purchase Download

Order RefP10 Download
Member Price £17.50 | $22.07 | €20.41
Non-member Price £52.50 | $66.21 | €61.22
