EV Drive-cycle Performance: Optimization and Thermal Analysis

This presentation was made at NAFEMS UK Conference 2018, Taking Engineering Analysis and Simulation to the Next Level".

The NAFEMS UK Conference 2018 brought together all those involved in analysis and simulation from every corner of industry and academia, giving them an opportunity to advance their knowledge, give their organisations a competitive advantage, and a chance to be part of improving the technology itself.

Resource Abstract

On the demand of getting more power, higher torque alongside with higher efficiency and low cost the optimization and thermal analysis of an electrical machine design is coming to the fore more and more.

With the latest changes mainly due to governmental restrictions or demands and directions the automotive industry is forced to undergo significant changes towards the electrification of the vehicles. This change in electrification is recognized in the aerospace and marine industry as well.

The intended presentation is showing for a mid-sized EV traction motor the design process in using modern state-of the art design tools. The design process takes into account the optimization of the machine using HEEDS in conjunction with SPEED, not only on a single load point but for a full drive cycle. The objectives hereby are: minimizing the material cost and maximizing the averaged efficiency over the load cycle.

As the maximum torque is mostly limited by the maximum winding temperature which is dependent on the selected insulation class, it is essential to predict the temperature and keep it below the limits of the corresponding insulation class which is also influencing the cost of the machine. The initial design of the machine and its required torque is done by using our SPEED™ software an analytical tool supported by electromagnetic 2D FE analysis. From those calculations we can derive the losses in the active material parts, such as copper, magnets and iron – which are itself temperature dependent. Additionally mechanical (bearings, windage and friction) losses can be analytical estimated. By coupling STAR-CCM+® and SPEED, both flow/thermal and electromagnetic aspects can be tackled in the same working environment, resulting in a better, optimized design process. The thermal analysis of electric motors is a complicated process because of the multiple heat transfer paths within the motor and the different materials and thermal interfaces through which the heat must pass to be removed. A full 3D CHT analysis takes all the different heat transfer path directly in the electrical machine and its applied cooling system into account. The thermal analysis is carried out again for the whole drive cycle. Finally a Co-Simulation approach which decouples the time-scales of the fluids and the solid parts in the CHT calculation speeds up the simulation time significantly.

Document Details

ReferenceC_Jul_18_UK_36
AuthorHolst. S
LanguageEnglish
TypePresentation
Date 17th July 2018
OrganisationCD-adapco
RegionUK
